Tri Axle Rear Dump Semi Trailer

Designed by Chinese trailer manufacturer DERUN, the tri axle rear dump semi trailer is a game changer in material handling. It combines strength, versatility and efficiency, making it the preferred choice for professionals in the construction, mining and agricultural sectors. With its rugged design and seamless operation, this trailer promises to revolutionize the way bulk materials are transported and unloaded.

Send Inquiry

Product Description

DERUN versatile and rugged tri axle rear dump semi trailer is designed for efficient and seamless material handling in a wide range of industries. This heavy-duty trailer boasts excellent load-carrying capacity and quick unloading capability, making it an indispensable asset for construction sites, mining operations and agricultural applications.

Tri Axle Rear Dump Semi Trailer Introduction

DERUN tri axle rear dump semi trailer is designed to meet the demanding needs of modern material handling. Its rugged construction utilizes a high-strength steel frame and durable components to ensure durability and longevity even under the harshest conditions. The trailer's hydraulic system is driven by a powerful pump that seamlessly lifts and tilts the box to quickly release materials such as gravel, sand, dirt and even mined ore.

Tri Axle Rear Dump Semi Trailer Parameter (Specification)

Box Body
Dimension	10000mm×2500mm×3700mm (The final size is according to the drawing)
Box size（Inner Size）	9300mm×2300mm×1900mm
Tare Weight	About 13500kg
Total Volume (m³)	40 m³
Side wall thickness	6 mm (Imported wear-resistant steel)
Bottom plate thickness	8 mm (Imported wear-resistant steel)
Lifting system	Full set of HYVA Hydraulic Lifting Cylinder (imported with original packaging)
Chassis
Axle	3pcs, 13T/16T, BPW/FUWA /DERUN
Landing Gear	JOST E100, double speed type;
King Pin	JOST 2.0/3.5 inches king pin
Suspension	Mechanical Suspension / air suspension / Bogie suspension (Germany Type or America Type)
Leaf Spring	90(W)mm×16(Thickness)mm×10 layers， 6 sets
Pneumatic Braking System	Dual lines air brake system with WABCO valve；with ABS
Rim	8.5-22.5, 12 pcs rims;
Tire	12R22.5, 12.00R20,315/80R22.5,12 pcs
Painting	Sandblasted, anti-rust chassis surface is available with 1 layer of anti-corrosive primer and 2 layers of topcoats.
Color	Optional, to be determined by customer
Accessories	One standard tool box, one spare tire carrier.

Tri Axle Rear Dump Semi Trailer Feature And Application

DERUN tri axle rear dump semi trailer is essential for construction projects, efficiently transporting and dumping aggregates, reducing the need for labor and speeding up the construction process. In the mining industry, the high capacity and fast unloading capabilities of these trailers make them ideal for transporting and unloading minerals and ores from mines to processing plants.

Tri Axle Rear Dump Semi Trailer Details

DERUN tri axle rear dump semi trailer is constructed of high quality materials to withstand the rigors of daily use and harsh environments. Smooth and efficient unloading process controlled by a user-friendly hydraulic system minimizes downtime and maximizes operational efficiency.
