4 Axle Side Tipper Semi Trailer

DERUN 4 axle side tipper semi trailer represents a significant advancement in heavy-duty transportation solutions, combining durability, functionality and safety into one rugged package. Whether you're managing a construction site or overseeing logistics operations, the trailer is a reliable partner that delivers results. If you are interested in DERUN 4 axle side tipper semi trailer’s price, welcome to consult us!

Send Inquiry

Product Description

DERUN 4 axle side tipper semi trailer for sale is a versatile choice for logistics and construction companies. Equipped with four axles, this trailer provides a stable platform that can handle uneven terrain and heavy loads, ensuring a smooth operation every time. The side-roll design allows for easy unloading, making the 4 axle side tipper semi trailer an indispensable tool in industries where efficiency and capacity are critical.

4 Axle Side Tipper Semi Trailer Introduction

DERUN 4 axle side tipper semi trailer is crafted from rugged materials to withstand the rigors of everyday use. Its tipping mechanism facilitates unloading without the need for specialized equipment, saving time and reducing operating costs. The trailer's body is typically made of high-strength steel or aluminum, providing durability while reducing weight to maximize payload. In addition, the suspension system on 4-axle rollover semi-trailers is designed to absorb shock and maintain stability during transportation, which is critical when dealing with challenging road conditions.

4 Axle Side Tipper Semi Trailer Parameter (Specification)

Box Body

Dimension

10000mm×2500mm×3700mm (The final size is according to the drawing)

Box size(Inner Size)

9300mm×2300mm×1900mm

Tare Weight

About 13500kg

Total Volume (m³)

40 m³

Side wall thickness

6 mm (Imported wear-resistant steel)

Bottom plate thickness

8 mm (Imported wear-resistant steel)

Lifting system

Full set of HYVA Hydraulic Lifting Cylinder (imported with original packaging)

Chassis

Axle

4pcs, 13T/16T, BPW/FUWA /DERUN

Landing Gear

JOST E100, double speed type;

King Pin

JOST 2.0/3.5 inches king pin

Suspension

Mechanical Suspension / air suspension / Bogie suspension (Germany Type or America Type)

Leaf Spring

90(W)mm×16(Thickness)mm×10 layers, 8 sets

Pneumatic Braking System

Dual lines air brake system with WABCO valve;with ABS

Rim

8.5-22.5, 16 pcs rims;

Tire

12R22.5, 12.00R20,315/80R22.5,16 pcs

Painting

Sandblasted, anti-rust chassis surface is available with 1 layer of anti-corrosive primer and 2 layers of topcoats.

Color

Optional, to be determined by customer

Accessories

One standard tool box, one spare tire carrier.


4 Axle Side Tipper Semi Trailer Feature And Application

In the construction and mining sectors, DERUN 4 axle side tipper semi trailer has a place among the essential machinery. Its ability to transport large quantities of dirt, coal, ore and aggregates makes it an invaluable asset to these industries. The rollover feature is particularly useful in tight spaces where traditional end dumping is impractical or unsafe. In addition, DERUN 4 axle side tipping semi-trailer can be used in waste management operations where it can efficiently transport refuse from collection points to disposal sites.

4 Axle Side Tipper Semi Trailer Details

An in-depth look at the finer points of DERUN 4 axle side tipper semi trailer reveals a sophisticated design that prioritizes safety and ease of use. The trailer body can be hydraulically operated, giving the operator precise control over the unloading process. Safety features such as reinforced sides and sturdy frames ensure that cargo remains secure during transportation. In addition, the braking system on the 4-axle tipper semi-trailer is designed to provide reliable braking power even when fully loaded, thus improving overall safety on the road.
